HOME > PRODUCT > M301 Mifare Read/Write Module

M301 HF reader module fully support 13.56MHz contactless card for embedded application, which offer a low-cost and robust method of authentication for consumables, making ideal for medical, ticketing, security or other safety&identity applications.



M301 has multi-port for external communication and integrates all necessary components to driver directly matched antenna in integrated or external format.

Highlights

● 13.56MHz HF RFID  ISO14443A/B,ISO15693

● Multi Communication Interface for flexible integration as wiegand, TTL and serial port

● Selective card polling capability in multi block transfer

● Firmware updates via serial interface (loader required)

● Diversified integration platform: Windows 98/2000/XP/7; Vista; Server2003&2008, ME98; Linux; WinCE 6.0 above / CE.net

● Comprehensive development kit and testing environment by XID



                                                                                                                                              M301 OEM Plug and Play Read/Write Module

ISO14443A MIFARE®
MIFARE® Classic 4K, MIFARE® Pro(X), SLE55Rxx, SLE66CL160S, JCOP, Other
compatible cards;MIFARE Ultralight®,MIFARE UltralightC®
 ISO14443B
SRI512, SRI2K, SRI4K, SRIX4K, CEP AS (CSN)
ISO15693
 I-CODE ILT-M, I-CODE SLI-L/S, Tag-It, My-d, EM4035, HID iCLASS UID
Communication InterfaceRS232, RS485, Wiegand26, TTL
 Extended I/O port3I/O ports, the I/O ports provide TTL level interface for general-purpose using No current driving or input protecting circuits is associated with these I/O ports
Power Supply5VDC (±5%)
Power Consumption<120mA
Communication Rate424Kbit/s
Baud Rate9600 - 115200 Kbit/s (default 115200)
AntennaOne External Antenna
55*50*2.6mm
IndicationOne buzzer, Two LEDs (Red and Green)
Operating Temperature -20 to +65°C
Storage  Temperature -20 to +70°C
Humidity0 ~ 95% relative humidity non-condensing
Dimensions100mm*50mm*10mm (with Build-in Antenna)
50mm*46mm*10mm (with External Antenna)
Operating systemWindows 98/2000/XP/7; Vista; Server2003&2008, ME98; Linux; WinCE 6.0 above / CE.net

Specifications are subject to change without notice.

● Access control, hotel lock

● Automatic identification

● Car parking system, Turnstile system

● Payment system, Vending Machine, Koisk system

● Inventory tracking

● Navigation


Document Name Release Date Download
M300 series datasheet Sep-20-2017 download
