M501 UHF RFID module is a high-performance reader/writer designed by Soonke IOT Technology for high challenging RFID application environment. It employs the newest R2000 RF chip providing the customers unprecedented performance of reading and writing experience.
The modules have been tested for non-stop running, and results showed that our module can work ceaselessly for 180 days. The stability and reliability can perfectly meet our customers’ application requirements.
The maximum power output of this module is +30dBm, with 8dbi antenna, which can realize a efficient reading/writing distance of 10m or above, and over 400tags/s for tags identification. Meanwhile, the compact design makes this module smaller (58*38*4 MM), coupled with the low working voltage of 3.7V--5V, the module is particularly suitable for application in a device such as a handset.
This product is suitable for RFID intensive and more challenging environment and required a higher reading/writing performance, such as warehousing, logistics, production line management, etc..
Highlights
● Employed IMPINJ R2000 RF Chips, up to 110dbm receiving sensitivity and the high performance makes this module more suitable for harsh application environment.
●High stability and reliability, 60*24 hours high temperature of workstation, can work stably and continuous.
● Remarkable performance with 8dbi RF antenna, can achieve a reading distance over 10m per single tag.
●Remarkable performance in intensive taps reading can attain a taps identification rate of 400tags/s.
● Provide the most comprehensive functions SDK and ports, easy to integrate RFID software.
● Adopted integrating RF chip, module performance is more stable, and more suitable for harsh application environment.
● The use of carrier wave cancellation technology makes the tag reading more accurate and the reading scope wider.
● The smallest module volume (56.5*36.0*7.8 MM) in the same field and supply power of 3.7V--5V, it is especially suitable for handsets and other mobile devices.
● Enhance noise suppression for reliable data capture.
● High precision return signal strength (RSSI).
