R502 is a four port UHF RFID fixed reader, which embeds the M4 module. Its communication interfaces can be USB, RS485, RS232, and 100M Ethernet, etc.. It has four TNC antennae interfaces, with a protection level of IP64. Aluminium alloy of the whole body makes this reader more rugged and durable as well as the excellent heat dissipation capability, antijamming capability and lightning-proof ability.

R502 is suitable for RFID intensive and more challenging environment and required a higher reading/writing performance, such as warehousing, logistics, production line management, etc..

Highlights

●  Employed IMPINJ R2000 RF Chips, up to -82dbm receiving sensitivity and the highest performance in this field makes this module more suitable for harsh application environment.

● Remarkable performance, can achieve a reading distance over 8m for single tag reading with 8dbi RF antenna.

● Remarkable performance in intensive taps reading, can attain a tags identification rate of 400tags/s.

● Provide the most comprehensive functions SDK and ports, easy to integrate RFID software.

● Adopted integrating RF chip, module performance is more stable, and more suitable for harsh application environment.

● The use of carrier wave cancellation technology makes the tags reading more accurate and reading scope wider.

● Provide four TNC antennae interfaces, users can achieve superior reading performance with less equipment deployment.

● Enhanced noise suppression function for reliable data capturing.

● High precision return signal strength (RSSI).

● Excellent performance of anti-interference and lightning-proof design.

● Aluninium alloy enclosure, rugged and durable, remarkable performance of heat dissipation.

● Aesthetic appearance, easy to install.
