HOME > PRODUCT > R280 125KHz & Mifare Card Reader

R280 is an economical access door reader with full-featured and fashion design for access control solution. Its efficient signalization system makes sure that the reader is easily seen. It is a dual frequency reader to support RF card as ISO14443A Mifare, EM125KHz, EM410X meeting different customer's requirement. What's more, original compact design provide ease of installation in various door access indoor and outdoor applications.


  •  Multi RF card ISO14443A Mifare; EM125kHz,EM410X or compatible

  •  NXP Original RF Chip with 128bit encryption

  •  Wall mount keypad form factors allow for US and EU compatible mounting options; creating a simpler install process at each door

  •  Tamper detection senses any type of altering and prevents a security breach with the device

  •  Total Flexibility – easily integrate with other systems or any third control system

  •  IP65 waterproof for indoor and outdoor harsh environment use

  •  Authorized certifications as CE, Rohs, CCC, FCC

  •  Firmware online upgrade

  •  OEM/ODM service

  •  One year-warranty


                                                                                                           R280 Access Door Reader

Model NameR280E-X
R280E-X-K
R280M-X
R280M-X-K
R280EM-X
R280EM-X-K
ISO14443A Mifare Read/Write
EM125 kHz Card
RS232/485
Weigand26,34,40,42,50,56
Operating Voltage Range9-24V DC
Keypad4x3 keypads with backlight, Doorbell
Reading performanceISO14443A Mifare:>5cm,  EM125KHz>8cm
Sound &InterfaceBuzzer and multi-color LED
Operation ModeRFID Card, Password
Environmental RatingUL 294 Outdoor Rated
Panel ConnectionTerminal Strip
Operating Temperature-32˚ to 131˚ F (0˚ to 55˚  C)
Storage  Temperature-4˚ to 140˚ F (-20˚ to 60˚  C)
Operating Humidity5% to 95% relative humidity non-condensing
Dimensions5.2" x 2.4" x 0.9"(132mm x 62mm x 23mm)
CertificationsFCC Certification (US), CE(EU)
Housing MaterialUL94  Polycarbonate

E: EM125kHz technology,EM410X or compatible

M: ISO 14443A Mifare Read/Write

K: with Keypad

X: X=2-->RS232  X=4--> RS485


Specifications are subject to change without notice

  •  Access Control

  •  Club / Loyalty System

  •  Parking system

  •  Printer Secure System

  •  E-payment, E-ticket

Connection diagram2.png

Document Name Release Date Download
R280 Datasheet Jan-23-2018 download
